Description
Output power stéréo : Bridge Mode :
(RMS) (RMS)
4x1300w @ 8 ohms 2x2600w @ 16 ohms
4x2150w @ 4 ohms 2x4300w @ 8 ohms
4x3200w @ 2 ohms 2x6000w @ 4 ohms
Fequency response : 10Hz – 20 KHz / (±)0,35dB
THD + N : ≤ 0,5% @ 8Ω 1kHz
(20Hz – 20KHz)
S/N Rate : > 99 dB
(20Hz – 20KHz)
Crosstalk : > 70 dB
(1KHz)
Slew Rate : > 30w/µs
Damping Factor : > 3000 (8ohms) 20 Hz to 100Hz
Voltage GAIN : 42,5 dB (0.775v : 103v)
Input Sensitivity : 0.775v ,1v ,1.4v, 2v
Input Impendance : 10K Ω balance/20K Ω unbalance
Input connectors : XLR Active balance
pin1 gnd/ pin2+ /pin3-
Output connectors : 4 Neutrik NL4 Sockets
Protection : Short circuit , DC, overload,
ultrasonic, RF, voltage peak limit it
Operating Voltage : 110V/220V available
Fuse : F-30A
Power consumption : <145w (Idle) Power consumption : <5000w (Max) Circuit : Class D
